FDL
FDL is specified when one downlight family must solve many problems.
With three frame options and a wide range of sizes, colour temperatures, and wattages, FDL scales effortlessly from small, focused spaces to large, complex projects. It is suitable for commercial and public environments, healthcare and residential applications and, with its IP65 rating, for covered exterior areas as well.
The family includes multiple styles to suit differing functional and aesthetic requirements. Flush and proud variants feature a tempered glass cover, delivering IK06 or IK08 impact resistance, while the secure version achieves IK10 through a polycarbonate cover combined with four fixing screws and spring clips to resist tampering and rip-out.
FDL is not a collection of one-off fittings.
It is a comprehensive specification tool - designed to standardise performance while accommodating the realities of different sites and uses.


Features
Optics: 75° & 90° beam angles, Opal primary optic, specular reflector
Light Source: SMD 2835
Mounting Type: Recessed
Finish: White | Black
Warranty: 5 Years
CRI: >80
CCT: 3 CCT: 3000K + 4000K + 5700K (Selectable)
Colour Consistency (LED Module): 3 SDCM
Output: 950 - 3850lm
Lifetime: L90@37,000 Hours | L80@80,000 Hours
IP65
IK06 - IK10
Operating temperature: -20°C - +45°C
UGR: <19
Application
Commercial, Education Facilities, Office, Residential, Transport
Product Dimensions

Fitting Dimensions
(Flush/Secure - D110) D: 110 | H:51 | CO: 90-95
(Flush/Secure - D150) D: 150 | H: 64 | CO: 125-140
(Flush/Secure - D172) D: 172 | H: 69 | CO:150-165
(Flush/Secure - D220) D: 235 | H: 81 | CO:200-220
(Proud - D150) D: 145 | H: 82 | CO: 125-135
(Proud - D172) D: 172 | H: 69 | CO:150-160
(Proud - D220) D: 220 | H: 104 | CO:200-210
*All dimensions shown are in mm, unless otherwise mentioned
