OMBRE GRID

Ombre Grid brings structure to the ceiling, and calm to the space below.
Defined by its disciplined geometry and finely diffused light, Ombre Grid establishes a visual rhythm that reinforces architectural order rather than competing with it. The grid becomes part of the architecture - quietly organising the ceiling plane while delivering consistent, high-performance illumination.
Designed for both recessed and surface-mounted applications, Ombre Grid allows architects to maintain compositional continuity across offices, reception areas, meeting rooms and boardrooms. In retail and healthcare environments, its controlled diffusion supports visual comfort and spatial clarity, without breaking the architectural narrative.
This is lighting for architects who think in lines, proportions, and systems - where repetition is intentional, and every element earns its place.
Ombre Grid does not decorate the ceiling; it completes it.

Features

Optics: Microprism centre diffuser, secondary side diffuser & outer fine rib transition diffuser

Mounting Type: Recessed | Surface mount

Finish: Whi t e | custom on request

Warranty: 5 Years

CRI: >80

CCT: 4000K | 3000K optional

Colour Consistency (LED Module): 3 SDCM

Lumen Output (Combined Board): 1200 - 3600lm

Lifetime: L90 (B10) 60,000 Hours

UGR: >19

Application

Commercial, Health Facilities, Office

Product Dimensions

Fitting (6x3)

W: 290 | L: 590 | H: 65

Fitting (12x3)

W: 290 | L: 1190 | H: 65

*All dimensions shown are in mm, unless otherwise mentioned

Resources

Data Sheet

Photometrics
